IPS05H10-EM
IPS05H10-EM
- IP66 waterproof design for installation in outdoors
- PoE eliminates need for local power supply
- Support web firmware upgrade for easy maintenance
- Standard SIP protocol to compatible with other SIP devices
- Support pre-recorded messages
- Support HTTP API for alarm in transmit
- Support RTP Multicast as alternation of SIP backend system
|
Audio |
|
|
Codec |
G.711 PCMU 8 kHz, G.711 PCMA 8 kHz |
|
Audio Input |
Built-in Mic |
|
Speaker |
|
|
Max SPL |
100dB |
|
Frequency Response |
300Hz ~ 8kHz |
|
Signal to Noise Ratio |
91dB |
|
Network |
|
|
Security |
Password protection, complicated password, HTTPS encryption, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface, Digest authentication |
|
Network Protocol |
SIP, ONVIF, HTTP, IPv4, DHCP, RTSP, RTP, RTCP, TCP, UDP, ARP, NTP |
|
Network Interface |
10/100 Base-TX, RJ45 |
|
VoIP |
Support for SIP protocol for integration with VoIP systems, integrated with SIP/PBX. |
|
Support ONVIF protocol for interaction with security systems, integrated with ONVIF VMS/NVR. 2 SIP Accounts, RTP Multicast |
|
|
Support codecs: G711U, G711A, MP3 |
|
|
Amplifier |
|
|
Amplifier Description |
Built-in 10W Amplifier |
|
Interface |
|
|
Alarm Input |
Alarm in x2 |
|
Audio Input |
Audio in x1 |
|
Local Storage |
Built-in 2Gb NAND Flash (Audio file storage is 100MB.) |
|
General |
|
|
Operating Conditions |
(-25℃ ~ +55℃) (-13°F ~ 131°F) Humidity 95% or less (non-condensing) |
|
Protection Level |
IP66 |
|
Power Consumption |
10W |
|
Power Supply |
POE (802.3af) |
|
Installation |
Wall mounted |
|
Material |
ABS |
|
Dimensions |
Φ 5.51'' x 7.48'' (Φ 140 x 190 mm) |
|
Net Weight |
2.2 lb (1kg) |
|
Languages |
English |
|
Warranty |
2 years |
