IPC8TF4R8-AD2
IPC8TF4R8-AD2
- High quality imaging with 8MP resolution
- AI-ISP for excellent noise reduction effect
- 24/7 colorful imaging via AI-ISP technology
- Clear imaging against strong backlight due to 130dB WDR technology
- Focus on Person and Vehicle classification based on deep learning
- Built-in arrayed dual-microphone for real-time high quality audio security
- Provide real-time security via built-in two-way audio
- Built-in RS-485
- Smart Dual Light: Integrates IR and White lights, 3 supplemental lighting modes
- Water and dust resistant (IP67)
- Active strobe light and audio alarm to warn intruders off
|
Camera |
|
|
Image Sensor |
1/1.8" Progressive Scan CMOS Sensor |
|
Min. Illumination |
Color: 0.0005 Lux ( F1.0 , AGC ON ) , 0 Lux with light |
|
Illumination Distance |
30m (IR light) 30m (warm light) |
|
Strobe Light |
N/A |
|
Smart IR |
Support |
|
Pan/Tilt/Rotation Range |
Pan: 0° ~ 360° Tilt: 0° ~ 75° Rotation: 0° ~ 360° |
|
Lens |
|
|
Focal Length |
2.8 mm |
|
Aperture |
F1.0 |
|
FOV |
Horizontal FOV: 108°, Vertical FOV: 59°, Diagonal FOV: 130° |
|
Lens Mount |
M16 |
|
Compression Standard |
|
|
Video Compression |
H.264/H.264+/H.265/H.265+/MJPEG |
|
H.264 Codec Profile |
Base/Main/High profile |
|
H.265 Codec Profile |
Main Profile |
|
Video Bit Rate |
11 Kbps ~ 16Mbps |
|
Triple Streams |
Support |
|
Audio Compression |
G.711A, G.711U |
|
Audio Bit Rate |
64 Kbps |
|
Image |
|
|
Max. Image Resolution |
8MP (3840 × 2160) |
|
Main Stream |
50Hz: 25fps 8MP (3840 × 2160) , 25fps 6MP (3200 × 1800) , 25fps 5MP (3072 × 1728) 25fps 4MP (2560 × 1440) , 25fps 1080P (1920 × 1080) 60Hz: 30fps 8MP (3840 × 2160) , 30fps 6MP (3200 × 1800) , 30fps 5MP (3072 × 1728) 30fps 4MP (2560 × 1440) , 30fps 1080P (1920 × 1080) |
|
Sub Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
|
Third Stream |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
|
Image Setting |
Brightness/Contrast/Saturation/Hue/Sharpness |
|
Shutter Time |
Auto/Manual, 1/3 ~ 1/100000s |
|
Day/Night |
IR Cut Filter |
|
Wide Dynamic Range |
130 dB |
|
Digital Noise Reduction |
2D/3D DNR |
|
BLC |
Support |
|
HLC |
Support |
|
ROI |
Support |
|
Rotate |
Support |
|
Smart Feature |
|
|
Basic Event |
Motion detection,video tampering |
|
Smart Event |
Line crossing, area intrusion, region entrance, region exiting (support alarm triggering by specified target types (human and vehicle, motorcycle) ) Scene change detection |
|
People Counting |
Support |
|
Loitering Detection |
Support |
|
Face Detection |
Support |
|
Network |
|
|
Network Storage |
NAS (NFS, SMB/CIFS) |
|
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, UPnP, SMTP, UPnP-TM, P2P |
|
System Compatibility |
Onvif (Profile S, Profile G, Profile T) , SDK |
|
Security |
HTTPS encryption, IP address filter, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
|
User |
Plug-in required live view: IE 10, IE 11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+ |
|
Web Browsers |
Up to 40 users |
|
Mobile Surveillance |
IOS, Android |
|
Active Deterrence |
|
|
Red/Blue Light Warning |
Support |
|
Sound Warning |
Support |
|
Interface |
|
|
Communication Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
|
On-board Storage |
Up to 512GB |
|
MIC |
Support |
|
Speaker |
Support |
|
Audio I/O |
1/1 |
|
Alarm I/O |
1/1 |
|
RS485 |
Support |
|
Reset Button |
Support |
|
General |
|
|
Operating Conditions |
(-40°C ~ 60°C) (-40°F ~ 140°F) |
|
Power Supply |
DC12V ± 25% |
|
POE |
PoE (802.3 af) |
|
Power Consumption |
MAX. 9 W |
|
Protection Level |
IP67 |
|
Material |
Metal |
|
Dimensions |
Φ 5.68'' × 4.47'' (144.5 × 113.5mm) |
|
Gross Weight |
2.33 lb (1057 g) |
